Understanding Differential Pressure Flow Meters: Principles, Applications, and Advantages

The differential pressure(DP) flow meter is one of the most widely used devices for measuring the flow rate of liquids, gases, and steam.

It is based on Bernoulli's equation, which states that as a fluid's speed increases, its pressure decreases. This simple yet effective measurement technique makes the DP flow meters effective for various industrial applications.

This blog will teach how DP flowmeters work, their different types, advantages, and applications.

How Does a DP Flow Meter Work?

Here's how the Differential Pressure (DP) flow meter works:

Primary element: The DP flowmeter has a primary element, like an orifice plate, venturi tube, or flow nozzle, which is installed in the pipeline. These elements create restrictions in the flow path.

Pressure Difference: When fluid flows through this restriction, it causes a pressure drop. The pressure before the restriction (upstream) is higher than the pressure after the restriction (downstream).

Measuring Differential Pressure: Two pressure taps are placed on either side of the primary element to measure the pressure difference (ΔP). One tap is located upstream, and the other is downstream of the restriction.

Flow Rate Calculation: The differential pressure (ΔP) created by the flow is related to the flow rate. The flow rate can be calculated using the Bernoulli equation and specific calibration data for the primary element.

In simple terms, a DP flow meter measures the difference in pressure across a restriction in the pipe. This pressure difference is then used to calculate the flow rate of the fluid.

(ΔP) is the differential pressure across the restriction.

Types of DP Flow Meters

Orifice Plate Flow Meter: In orific flow meters, an orifice plate is used with a hole(orifice) in the middle to create a restriction. The differential pressure is measured across the orifice plate.

Venturi Tube Flow Meter: In a venturi tube flowmeter, a tube with a narrow section in the middle is used, and the pressure is measured at two points: at the entrance of the tube (before the narrow section) and at the throat (the narrow section). The pressure difference is measured between these two points.

Flow Nozzle Flow Meter: The flow nozzle flow meter consists of a nozzle-shaped restriction that creates a differential pressure.

V-Cone Flow Meter: A V-cone flow meter has a cone-shaped restriction placed in the center of the pipe, which creates a pressure difference.

Need to optimize your flow performance? Choose Burak flow meters for accurate, reliable, and cost-effective solutions in various applications. Contact us today to enhance your flow measurement processes!

Applications of DP Flow Meters

Oil and Gas Industry

In the Oil and gas industry, DP flow meters are used to measure oil and gas during transfer between parties to ensure proper billing.

It also measures the flow of hydrocarbons in pipelines and processing facilities.

Water and Wastewater Industry

They measure the flow of water in distribution networks to ensure efficient supply and detect leaks in the water and waste water industry.

Chemical and Petrochemical Industry

DP flow meters in the petrochemical industry measure the flow of various chemicals and petrochemicals in processing plants.

Power Generation

In power generation, DP flow meters measure the steam flow in power plants, the flow of cooling water in power plants, and the flow of fuel in the power generation system.

HVAC (Heating, Ventilation, and Air Conditioning)

They measure the air flow of chilled water and monitor energy consumption in the HVAC system.

Food and Beverage Industry

DP flowmeters in the food and beverage industry measure the flow of liquids like water, juice, and syrup used in production processes.

Pharmaceutical Industry

In pharmaceuticals, they measure the flow of various fluids, such as water, solvents, and liquid medicines, in pharmaceutical production.

Advantages of DP Flow Meters

• It works in gas, steam, and liquid applications
• DP flow meters do not rely on the fluid's electrical properties, they can be used with a wide range of fluids, regardless of their conductivity.
• They can measure low flow rates and thick, sticky fluids like tar and sludge and can also handle some solid particles in the fluid.
• Diffrencial pressure meters are usually cheaper or more cost-effective than other flowmeters.
• Some types of DP flow meters create very little pressure drop, like flow nozzles and pitot tubes.

Limitations of DP Flow Meters

• DP flow meters work well within a specific range of flow rates. However, they may not be as accurate while measuring very low or very high flow rates.
• The impulse lines (pipes that carry the pressure signal) require frequent maintenance to save them from clogging or freezing.
• To work properly, they need straight sections of pipe before and after the meter, usually at least 25 pipe diameters upstream and 10 diameters downstream.
• The permanent pressure drop from orifice plates can lead to higher energy costs over time.
• Diffrential pressure flow meters are not suitable for small pipes that are smaller than 6 inches in diameter.

Explore other flow meter types and their applications – Read here!

 Factors to Consider When Choosing a DP Flow Meter

• Clearly understand the purpose of the DP flowmeter in your process. Like what specific measurement needs do you have?
• Determine how the DP flow meter will integrate with the existing system.
• Identify the type of fluid you have to measure
• Determine the range of flow rates that need to be measured
• Ensure the DP flow meter is suitable for the pipe size in your system. For small pipes (smaller than 6 inches)
• Verify that there is enough straight pipe length upstream and downstream of the meter to establish a good flow profile. This is usually at least 25 pipe diameters upstream and 10 diameters downstream.
• Consider the maintenance requirements of the DP flow meter
• Evaluate the cost of the DP flow meter.

Choose DP Flow Meter if;

• Your Application Involves Gas, Liquid, or Steam
• You Need a Reliable and Cost-Effective Solution
• Require Accurate Measurements Over a Specific Range
• You Have Enough Straight Pipe Length(usually at least 25 pipe diameters upstream and 10 diameters downstream)
• Fluid's Conductivity is Not a Factor
• You Can Handle Periodic Maintenance
• Low Flow Rates and Thick, Sticky Fluids need to be measured
• Need a Long-Term Reliable Solution

Summing up!

Differential Pressure (DP) flow meters are versatile and reliable tools that are widely used in various industries.
